thermal reactor
The reactor is widely applied in multiple industries including petroleum, chemical engineering, rubber processing, pesticide production, pigment and dye manufacturing, pharmaceutical production as well as food processing. It is specially adopted for technological processes such as vulcanization, oxidation, alkylation, polymerization and condensation reactions.
Product Overview
The reactor is widely applied in multiple industries including petroleum, chemical engineering, rubber processing, pesticide production, pigment and dye manufacturing, pharmaceutical production as well as food processing. It is specially adopted for technological processes such as vulcanization, oxidation, alkylation, polymerization and condensation reactions.
Technical Parameters
Body material: Adopts high-quality stainless steel materials including SS304 and SS316L for stable performance and corrosion resistance.
Structure: Divided into three main types: open-type reactor with flush cover, open welded flange-type reactor and fully closed reactor.
Composition: The complete equipment consists of reactor body, tank cover, jacket layer, stirring device, transmission mechanism, shaft sealing device and supporting legs.
Surface treatment: The inner and outer surfaces can be treated by mirror polishing or wire drawing process according to actual demands.
Optional Accessories
- Sterile filter
- Digital/dial type thermometer
- PH detection meter
- Sanitary grade manhole
- Material outlet port
- Automatic cleaning ball
- Pressure gauge
- Sterile sampling valve
- Liquid level meter and liquid level controller (optional types: load-bearing module type, non-contact ultrasonic type, static pressure transmitter type)
Technical Specifications
| Model | Volume (L) | Inner pot size (mm) | Outer pot size (mm) | Motor power (KW) | Mixing speed (R/m) |
| YRK-50 | 50 | 400 | 600 | 1.1 | 60-80 |
| YRK-100 | 100 | 500 | 700 | 1.5 | 60-80 |
| YRK-200 | 200 | 600 | 800 | 2.2 | 60-80 |
| YRK-300 | 300 | 700 | 900 | 3 | 60-80 |
| YRK-500 | 500 | 900 | 1100 | 4 | 60-80 |
| YRK-1000 | 1000 | 1200 | 1400 | 5.5 | 60-80 |
| YRK-2000 | 2000 | 1500 | 1700 | 7.5 | 60-80 |
| YRK-3000 | 3000 | 1600 | 1800 | 15 | 60-80 |
| YRK-5000 | 5000 | 1800 | 2000 | 15 | 60-80 |
| YRK-10000 | 10000 | 2000 | 2200 | 18 | 60-80 |
The material and size is customizable. Or tell us your requirements and we will suggest the suitable product.
