Stainless steel pipe bend

Product Overview

Our company specializes in various stainless steel elbows, using carefully selected high-quality stainless steel raw materials such as 304, 304L, 316, and 316L. We strictly adhere to domestic and international industry standards such as GB/T12459 and ASME B16.9 in our manufacturing process. Our products are highly adaptable and widely used in pipeline transportation systems across various fields, including petroleum, chemical, pharmaceutical, food processing, and shipbuilding. They are core supporting accessories for industrial pipeline laying and renovation.

Product Series Details

1. 90-degree stainless steel elbow

As a core component for conventional pipeline turning, it is suitable for most right-angle pipeline laying scenarios, with comprehensive specifications and diverse molding processes.
Specification range: DN15-DN600
Wall thickness grades: SCH5S-SCH160
Forming processes include hot pressing (R=1.5D) and cold bending (R=3D). Large-diameter welded elbows can also be customized to meet installation requirements under various working conditions.

2. 45-degree stainless steel elbow

Suitable for pipelines with minor turns, it features a high degree of standardization, flexible connection methods, and a complete surface treatment process, making it suitable for high-standard working conditions such as cleanliness and corrosion resistance.
Implementation standard: GB/T12459-2017
Connection methods: Supports three mainstream methods: butt welding, socket welding, and threaded connection.
Special treatments: Acid pickling and passivation, electropolishing can be performed to improve the product’s corrosion resistance and surface finish.

3. 180-degree stainless steel bend pipe

It features high pressure resistance and wide temperature range adaptability, with a wide range of material options, and can be adapted to special pipeline conditions with extreme high and low temperatures and high pressure.
Available materials: 304, 316, 321, 310S
Pressure rating: PN10-PN100
Applicable temperature range: -196℃ to 800℃, suitable for special operating environments such as low-temperature cold chain and high-temperature heat exchange.

Core Product Advantages

Reliable and durable materials: Made from carefully selected high-quality stainless steel sheets, the material is pure and stable, with excellent corrosion resistance and oxidation resistance, making it suitable for complex industrial environments.
Exquisite and standardized craftsmanship: The product is formed by a fully automatic pipe bending machine, resulting in uniform wall thickness and standard curvature, effectively avoiding problems such as blockage and excessive resistance in pipeline medium transportation.
Outstanding surface precision: The inner and outer walls of the product are finely polished, with a surface roughness Ra≤0.8μm, smooth and free of burrs and impurities, and not easy to accumulate dirt, making it suitable for clean pipeline requirements in food, pharmaceutical and other industries.
Precise and controllable dimensions: 100% full-size inspection is carried out at the factory, and all parameters are strictly controlled to fully guarantee the accuracy of on-site installation and reduce construction errors.

Wide range of applications

With its excellent product performance and stable quality, this series of stainless steel elbows is suitable for core pipeline systems in many industries. The main application scenarios include: oil and gas transmission pipelines, chemical corrosion-resistant pipeline systems, food and beverage production equipment pipelines, pharmaceutical industry clean pipelines, marine pipeline systems, industrial heat exchange systems, etc.
