Options and Agitators
This product offers a variety of optional functions and configurations to meet different process requirements:
The tiltable design facilitates unloading and cleaning.
Integrated control panel for intuitive and convenient operation
A wide selection of mixers is available, including
- frame mixers
- anchor mixers
- scraper mixers
- propeller mixers
- bottom-driven mixers
- dispersion disc mixers
- rotor/stator mixers
- auger mixers
- high-shear mixers
- turbine mixers
- side-entry mixers
- static mixers
- external homogenizers.
- Multiple mixer combinations are also supported.
Heating and cooling methods: Heating or cooling can be achieved using honeycomb jackets or semi-circular tube jackets.
Precise measurement:
- Can be equipped with load cells and level switches
- Cleaning interface for easy online cleaning
- Skid-mounted structure, facilitating overall installation and relocation.
- Multiple surface finish grades are available.
Multiple materials:
- 304 stainless steel
- 316L stainless steel
- duplex stainless steel
Specifications Table
| Model | Volume (L) | Dimensions (mm3) | Motor power (kw) | Speed (r/min) |
| YMT-T-50P | 50 | 400×400×1600 | 0.55 | 120 |
| YMT-T-100P | 100 | 500×500×1700 | 0.75 | 120 |
| YMT-T-200P | 200 | 700×500×1800 | 1.1 | 120 |
| YMT-T-500P | 500 | 9500×1100×2000 | 1.5 | 120 |
| YMT-T-1000P | 1000 | 1000×1200×3300 | 2.2 | 120 |
| YMT-T-2000P | 2000 | 1200×1500×3200 | 3 | 100 |
| YMT-T-5000P | 5000 | 1800×1800×4000 | 5.5 | 36 |
| YMT-T-10000P | 10000 | 2400×3600×6000 | 7.5 | 36 |
